Five Function Manual ICU Bed (ABS)

Buffer to Buffer 2090 mm x 1015 mm

Mattress Platform 1885 mm x 870 mm

Backrest 0° - 75°

Max. Height (Incl. Mattress) 815 mm

Min. Height (Incl. Mattress) 582 mm

Trendelenburg 15°

Reverse Trendelenburg 8°

Specifications

• The Height, Backrest, Kneerest, Trendelenburg & Reverse trendelenburg

adjustments are done by screw-lever mechanism. Calf elevations can be ad-

justed manually using ratchet. Screw levers handles are fold-able.

• Manually adjustable calf elevation.

• Collapsible Aluminium side rails to prevent patients from fall.

• The ABS head and foot boards can be removed when needed.

• 5” Heavy duty castor wheels with brakes on adjacent side, buffers for shock

absorption.

• 4” High density mattress with Antimicrobial, Flame retardant and water re-

pellent properties. Four sectional mattress.

• Urine bag holder, heavy duty I.V. pole.
